Dallas Data Center DAB (DAL II)
2440 Marsh Lane, Dallas, TX
At a glance
2440 Marsh Lane, Dallas, TX
Areté Solutions’ Dallas Data Center DAB (DAL II) is located at 2440 Marsh Lane and is an ideal facility for companies seeking a colocation data center, business continuity and disaster recovery centers, and managed IT services from an enterprise quality, metro Dallas data center.
12,500
Data center space
Move-in-ready space.
562 kW
Total power capacity
Space offers a total capacity of 562KW of power.
17 mi
From downtown Dallas
Easily accessible from DFW Airport and Dallas Love Field.
Facility specifications
What’s inside.
Facility details
- Located just 17 miles from downtown Dallas and is easily accessible from DFW Airport and Dallas Love Field
- Features 12,500 of move-in-ready data center space
- The building is strategically located outside of the 500 year flood plain
- Facility has diverse and redundant utility feeds, and has diverse entry points for fiber to the facility
Security
- Facility is enclosed by vehicle barrier fencing
- Areté Solutions provides 24 X 7 days a week on-site uniformed security, including man cage at main entry
- Cage access is controlled by biometric and/or key card access readers
- Each secure data center has a minimum of four security checkpoints that are keycard and/or biometric access controlled
- All access points, common areas and the building perimeter are monitored by CCTV at the data center security station and remotely at a NOC facility
- Security images are maintained in accordance with PCI requirements
- The generator yard is located behind a retaining wall around the perimeter for security
Data center floor
- 12,500 of move-in-ready data center space
- 36-inch raised floor
- Secure cages and lockable cabinets solutions
Electrical power
- UPS is configured with 2 750 kVA N+1 UPS systems
- Power is served by two (2) sub-stations with diverse entry paths into the facility
- Each substation is served by separate power generation plants
- Served by Two 2,000 kW generators
- True A/B power is delivered to the data center floor with redundant PDUs and RPPs
- The generator yard is located behind a 30 ft. high retaining wall around the perimeter for security
- Generators are tested on a monthly basis
- Subterranean fuel storage tanks have a capacity of up to 48,000 gallons of diesel fuel
- The data center is supported by redundant re-fuel contracts
- Space offers a total capacity of 562KW of power
Cooling
- Dedicated 2N air-cooled chillers, bi-directional chilled water loop with 2N pumping and N+15% CRAH units to each 1125 kW data center
- Double-interlock, dry pipe, pre-action, water sprinkler system. Overhead and under floor smoke detection
Telecom & connectivity
- Fiber enters the building through two separate entrance facilities on different sides of the facility
- Areté Solutions has a private, DWDM fully redundant carrier grade fiber ring to connect Areté Solutions data centers to major carrier hotels
Carriers
- AT&T
- Time Warner
- Zayo
- XO
- Verizon
- Level3/CenturyLink
- Fiberlight
- Frontier
- IIX
